Wuhan Darppon is one of the leading medical equipment manufacturers and distributors in China since 2009. Dedicated to product development and production by independent teams, Darppon established Electrosurgical Unit, Patient Monitor, Electrocardiograph and Home Care production lines step by step, and we have passed ISO 1234 and CE certificates for all our products.
Up to now, Darppon specialize in offering more than 100 types of products which including Electrosurgical Unit, Patient Monitor, Electrocardiograph, Medical Imaging System, Infusion/Syringe Pump, Defibrillator, Home Care and Veterinary products etc. At present, Darppon products have been exported to over 100 countries and regions.
Inheriting the people-oriented principle, Darppon endeavor to creates united, competitive and positive working environment for our teams. Also, we always dedicate to research and develop advanced technology and products and hope to bring the highest satisfaction our customers worldwide.
Packaging&Shipping
Multiple delivery solutions, safe, fast, professional !
Introduction
This is special designed new product suitable for cerebral operation. It is suitable for surgical procedures of the neck, throax and abdomen, perineum and extremities as well as for gynaecological, oto-rhino-laryngological operations. It is a multi purpose operating table.
This operating table is feature is can be lowered to 550mm hight from floor for convenient doctors to seat operation. There is a special designed Head Rack.Its all movements are controlled electrically. It's noise is little, performance is reliable, adjustment is easy. Various positions of head section, back section, seat section, kidney bridge, bridge, leg section can be easy adjusted.
Technical specifications
Dimension of table top
| Overall Length | 2000mm |
| Width | 500mm |
Table top of from floor
| Max Height | 850mm |
| Min Height | 600mm |
Range of movements
| Reversed Tendelenburg | ≥200 |
| Lateral tilt | ≥150 |
Adjustment of sections
| Head Rack Upward or Dowmward | 180mm |
| Head Rack Adjust of Lengthways | 50mm |
| Head Rack Backward or Forward | 150mm |
| Back Section Raised from the horizontal | ≥50° |
| Back Section lowered from the horizontal | ≥15° |
| Kidney Bridge Elevated | ≥100mm |
| Leg Section Lowered from the horizontal | ≥90° |
| Leg section opened(when choose the detached leg section) | ≥90° |
Accessories
| Name of accessories | Qty | |
| 1 | Stand for anaesthetic bottle | 1 |
| 2 | Head section or head rack | 1 |
| 3 | Body support | Large 1.small 1 |
| 4 | Shoulder support | 2 |
| 5 | Arm rest | 2 |
| 6 | Knee crutch | 2 |
| 7 | Cushion | 1 |
